Semi-Electric Stacker With Adjustable Fork EMS series Double-Pallet Stacker FD series

▲ Capacity 1200kg, 1500kg
▲ Heavy duty design with quality construction. ▲ New tiller made by REMA, German
▲ Straddle leg design makes it more stable. ▲ Efficiently carry double pallets simultaneously.
▲ Semi-electric design to reduce labour intensity and raise working efficiency. ▲ High-comfort tiller grip reduces fatigue, improving productivity.
▲ This stacker can lift cargo and transport in short distance. L ▲ Heavy-duty design with top quality mast construction.
▲ It has been widely used in workshopawarehouseawharfastationadepot and so on. ▲ Powerful drive unit and power pack are made in Europe.
▲ Adjustable fork make it suitable for different pallet. ▲ Top quality electronic control system made in Europe.
▲ Conforms to EN 1757-1:2001, EN 1726

H
F

C Q

2500mm X A h

E B

FD1229
R
i-Lift No. 1551201 1551202 1551203 1551204 1551205 1551206
Model FD1224 FD1524 FD1229 FD1529 FD1233 FD1533
EMS1025 Capacity kg(lb.) 1200(2640) 1500(3300) 1200(2640) 1500(3300) 1200(2640) 1500(3300)
Lifting Height mm(in.) 2450(96.5) 2900(114.2) 3300(129.9)
Load Centre mm(in.) 600(26.8)
i-lift No. 1551901 1551902 1551903 1551904 1551905 1551906 1551907 1551908 Fork Length mm(in.) 1150(45.3)
Model EMS1016 EMS1025 EMS1030 EMS1033 EMS1516 EMS1525 EMS1530 EMS1533 Fork Width mm(in.) 680(26.8)
Capacity kg(lbs) 1000(2200) 1500(3300) Motors Travelling (W/V) 2000/24
Lifting height H mm(inch) 75-1600(3-63) 75-2500(3-98.4) 75-3000(3-118) 75-3300(3-130) 75-1600(3-63) 75-2500(3-98.4) 75-3000(3-118) 75-3300(3-130) Motors Lifting (W/V) 2000/24
Fork length L mm(inch) 915(36) Driver Wheel mm(in.) Ф230×75(9x3)
Outside width between forks E mm(inch) 190-800(7.5-31.5) 210-800(8.3-31.5) Front Roller mm(in.) Ф80×70(3x2.8)
Load center C mm(inch) 400(15.7) Rear Roller mm(in.) Ф140×60(5.5x2.4)
Min. outside turning radius R mm(inch) 2200(86.6) Battery (Ah/V) 240/24
Min. clearance from ground X mm(inch) ≥30(1.2) Net Weight kg(lb.) 850(1870) 875(1925) 897(1973.4)
380(15)
Max. lifting speed with full loading mm/s ≥70 ≥50 Dimension X mm(in.) 1431(56.3)
mm(in.)
Y
Lowering speed Controllable L1 mm(in.) 2080(81.9)
Lifting motor 12V/1600W L mm(in.) 2493(96.5)
Battery 12V/100Ah K mm(in.) 210(8.3)
Charger 200V/12V 110V/12V h1 mm(in.) 1804(71) 2029(79.9) 2229(87.8)
Length A mm(inch) 1550(61) h2 mm(in.) 2984(117.5) 3434(135.2) 3834(150.9)
Overall dimension Width B mm(inch) 1080-1360(42.5-53.5) h3 mm(in.) 90(3.5)
Height F mm(inch) 2020(79.5) 1770(69.7) 2020(79.5) 2170(85.4) 2070(81.5) 1770(69.7) 2020(79.5) 2170(85.4) N mm(in.) 190(7.5)
Load wheel mm(inch) 100(4) B mm(in.) 844(33.2)
Steering wheel mm(inch) 200(8) Wa 1625
Net weight kg(lbs) 366(805.2) 448(985.6) 468(1029.6) 480(1056) 390(858) 472(1038.4) 493(1084.6) 513(1128.6) Wa’ 1730
Wa” 2125
